MKP DC Link LSI

1.High ripple current handing capability
2.Low ESR and ESL
3.High capacitance density
4.Self-healing properties
5.Long life expectation

Application

Widely used in DC Link, high performance DC filtering, motor drive systems, welding machine, elevator, EV/HEV.

Product parameters

   Reference Standards

IEC /EN 61071, GB /T 17702

   Technical Specifications
·   CapacitanceCRRefer Data Sheet
·   Tolerance%J = ± 5% and K = ± 10%
·   Rated VoltageURDC (VDC)Refer Data Sheet
·   Max. Rated voltageVDC1.1URDC for maximum 30% of on-load duration
1.15 VR for maximum 30 minutes per day
1.2 VR for maximum 5 minutes per day
1.3 VR for maximum 1 minute per day
·   Insulation Resistance  τ = CR.Rins @ 20°C, RH≤65%τ (s)τ (s) > 10.000 s (after 1 minute)
For VR ≥500V measured at 500V
For VR < 500V measured at 100V
·   Reliability
   - Service Life tSL100.000h at VR @ THS = 70ºC
   - Failure rate (FIT) (1)  λ100IT at VR @ TAMB = 40ºC
   Thermal characteristics
·   Climatic Category as per IEC 60068-1
40/85/56
·   Max. Operating temperature (Hot spot temperature)T op(max.)+85 ºC
·   Upper category temperatureT max.+85 ºC
·   Lower category temperatureT min.- 40 ºC
·   Storage conditions
   - TemperatureT (ºC)-40 to +85 ºC
   - Maximum altitude/2000m above sea level(Derating curves available upon request)
   - Storage timeYearsMax. 3 years from the date market on package label

Product Application

FAQ

Q:

What is the process for customizing products? How long does it typically take?

A:
The customization process consists of five steps: 1. Requirements communication (clarifying parameters, application scenarios, and batch requirements); 2. Solution design (the technical team develops and confirms the customization solution); 3. Sample making (producing samples and conducting performance testing); 4. Customer verification (customer confirms sample compliance); 5. Mass production. The standard customization cycle is 15-30 days, depending on product complexity and order volume. Urgent requests can be expedited upon negotiation.
Q:

Does your company support customized capacitor services?

A:
Yes. For the specific needs of high-end fields such as new energy and medical devices, we can provide customized R&D and production services, covering personalized adjustments to key parameters such as capacitance, voltage, size, and temperature rating. We can also assist customers in completing sample testing and mass production coordination.
Q:

What are your company's core products? In which fields are they mainly used?

A:
Our core product is metallized polypropylene film capacitors, with a focus on the CBB series. These products are widely used in various fields, including new energy (photovoltaic inverters, energy storage PCS, SVG, new energy vehicles), home appliances (air conditioners, refrigerators, washing machines), power tools (water pumps, cleaning machines), and medical devices (defibrillators), meeting the high reliability requirements of different scenarios.
